Introducing Kernel Data Protection, a new platform security technology for preventing data corruption

Bot

AI-powered Bot
Thread author
Verified
Apr 21, 2016
3,323
Attackers, confronted by security technologies that prevent memory corruption, like Code Integrity (CI) and Control Flow Guard (CFG), are expectedly shifting their techniques towards data corruption. Attackers use data corruption techniques to target system security policy, escalate privileges, tamper with security attestation, modify “initialize once” data structures, among others.

Kernel Data Protection (KDP) is a new technology that prevents data corruption attacks by protecting parts of the Windows kernel and drivers through virtualization-based security (VBS). KDP is a set of APIs that provide the ability to mark some kernel memory as read-only, preventing attackers from ever modifying protected memory. For example, we’ve seen attackers use signed but vulnerable drivers to attack policy data structures and install a malicious, unsigned driver. KDP mitigates such attacks by ensuring that policy data structures cannot be tampered with.

The concept of protecting kernel memory as read-only has valuable applications for the Windows kernel, inbox components, security products, and even third-party drivers like anti-cheat and digital rights management (DRM) software. On top of the important security and tamper protection applications of this technology, other benefits include:

  • Performance improvements – KDP lessens the burden on attestation components, which would no longer need to periodically verify data variables that have been write-protected
  • Reliability improvements – KDP makes it easier to diagnose memory corruption bugs that don’t necessarily represent security vulnerabilities
  • Providing an incentive for driver developers and vendors to improve compatibility with virtualization-based security, improving adoption of these technologies in the ecosystem

KDP uses technologies that are supported by default on Secured-core PCs, which implement a specific set of device requirements that apply the security best practices of isolation and minimal trust to the technologies that underpin the Windows operating system. KDP enhances the security provided by the features that make up Secured-core PCs by adding another layer of protection for sensitive system configuration data.


The post Introducing Kernel Data Protection, a new platform security technology for preventing data corruption appeared first on Microsoft Security.

Last edited by a moderator:
F

ForgottenSeer 85179

Getting started with KDP
Both dynamic and static KDP do not have any further requirements other than the ones needed for running virtualization-based security. In ideal conditions, VBS can be started on any computer that supports:
  • Intel, AMD or ARM virtualization extensions
  • Second-level address translation: NPT for AMD, EPT for Intel, Stage 2 address translation for ARM
  • Optionally, hardware MBEC, which reduces the performance cost associated with HVCI

Ryzen <3000 don't have MBEC but since Ryzen 3000 that's included. (y)

  • Like
Reactions: shmu26

Stopspying

Level 19
Verified
Top Poster
Well-known
Jan 21, 2018
814
"Microsoft is testing a new Windows 10 security feature dubbed Kernel Data Protection (KDP) and designed to block malicious actors from corrupting drivers and software running in the Windows kernel.
"For example, we’ve seen attackers use signed but vulnerable drivers to attack policy data structures and install a malicious, unsigned driver," Microsoft said on the Security Kernel Core Team blog. "KDP mitigates such attacks by ensuring that policy data structures cannot be tampered with."
Besides adding memory and security protection to Windows 10 devices, KDP also comes with several added benefits, including:
Performance improvements – KDP lessens the burden on attestation components, which would no longer need to periodically verify data variables that have been write-protected
Reliability improvements – KDP makes it easier to diagnose memory corruption bugs that don’t necessarily represent security vulnerabilities
Providing an incentive for driver developers and vendors to improve compatibility with virtualization-based security, improving adoption of these technologies in the ecosystem"
